- Poles And Beams (BASE FRAME) used in manufacturing of steel sheet kiosks will be manufactured of 2mm pre-galvanized steel sheet , and will be powder coated with RAL electrostatic paint after the welding process.
- Air-cushioned seals will be used on each waterproof bend of the steel sheet kiosk,
- Doors of sheet metal kiosk will be manufactured from 2mm pre-galvanized steel sheets.
- 40-mm-thick Izocam will be used for door insulation,and covered with 1mm pre-galvanized steel sheet.
- Mesan 018 branded locks will be used on hinged doors.Latch elements used for locks will be round and wheeled.Slide bars will be mounted on the bottom and top of U-doors.
- Air deflectors will be mounted at the bottom of hinged doors,for protection from the wind.
- Flexi copper will be used for grounding doors.
- Covers of sheet metal kiosks will be manufactured from 2mm pre-galvanized steel sheets.
- 40-mm-thick Izocam will be used for cover insulation,and covered with 1mm pre-galvanized steel sheet.
- Covers will be fastened to the Base Frame with 3 double bend braces.
- Roofs of sheet metal kiosks will be manufactured from 2mm pre-galvanized steel sheets.
- 60-mm-thick insulation material will be used for roof insulation,and covered with 1mm pre-galvanized steel sheet,
- The bas efor the sheet metal kiosk will be selected in varying dimensions corresponding to the sheet metal dimensions provided below.NPU materials will be used is the base.
- The entire base will be coated with the hot dip galvanizing technique.The upper section of the base will be completely covered with 2mm pre-galvanized steel sheet.
- Bases will be equipped for 4 lifting hooks for sheet metal kiosks of up to 6meters,and 6 lifting hooks for sheet metal kiosks longer than 6 meters.
* Up to 1-4m in lenght: : 100NPU
* 4 - 6m : 120NPU
* 6 - 8m : 140NPU
* 8 - 10m : 160NPU
* Over 10m : 200NPU
